Saddle Cabinet
Description :
Product Description:
Customized Saddle Cabinet Technical Overview
Developed for specialized U.S. market requirements, this saddle cabinet exemplifies precision sheet metal fabrication with optimized structural and logistical features:
1. Material & Surface Treatment
- Base Material: Cold-rolled steel (SPCC/DC01) with 1.2-2.0mm thickness,
- selected for structural rigidity (tensile strength ≥270MPa) and formability
- Surface Finish: Electrostatic powder coating (RAL color matching) achieving:
- 60-80μm coating thickness
- Salt spray resistance ≥500h (ASTM B117)
- Custom chromaticity ΔE ≤1.5
2. Fabrication Process
- Welded-Assembled Hybrid Structure:
- Laser-cut components (±0.15mm dimensional accuracy)
- Robotic welding (MIG) for main frame
- Modular bolt-on panels (ISO 4762 hex socket screws)
- Reinforcement Design:
- Press-formed stiffening ribs (1.5mm depth)
- 25% increased torsional rigidity vs conventional designs
3. Logistics Optimization
- Flat-Pack Configuration:
- 40% volume reduction vs fully welded units
- CNC-bent interlocking flanges (90°±0.5°)
- Packaging Standard:
- Triple-wall corrugated with EPE cushioning
- Stacking strength ≥800kg/m² (ISTA 3A compliant)
4. Technical Compliance
- Meets ANSI/BIFMA X5.9 for commercial storage units
- UL-certified grounding continuity (≤0.1Ω resistance)
This engineering solution balances manufacturing precision (GD&T ASME Y14.5M) with cost-effective trans-Pacific shipping requirements, achieving 18% total landed cost reduction versus traditional all-welded cabinets.
| Product name: | Saddle Cabinet |
| Material | Carbon steel, SPCC, SGCC, Stainless steel, Aluminum, Brass, Copper, etc. |
| Size: | Customized. We need your drawings in CAD, 3D or PDF. Or you send us your sample, we draw for you |
| Fabrication processes: | Getting your order – Caculating material QTY needed & open tooling – Material stock – Fabrication dawings – Material laying off – Stamping – fix the burrs – surface treatment – quality inspection – packing |
| Surface treatment: | Polishing, Zinc plating, Powder coating, Chrome plating, Nickel plating |
| logo: | Silk print, Laser marking |
| Color: | Customized |
| Application: | Industry, Electrical industry, Mining industry, mechanical, metals, components for furniture, auto, machines etc |
| Sample lead time: | No surface treatment, 1-3 workdays. |
